Name: Heavy Duty Fixed Joints with 10-250KN Rated Load for Permanent Structural Connections in Electrical Construction
Brand: Ningbo Suntech Power Machinery Tools Co.,Ltd.
SKU: S.L.U
Price: 285,715.00 USD
Availability: InStock

Caratteristiche Galleria Descrizione di prodotto Richieda una citazione

Caratteristiche

Specificazioni

Nome: Giunti fissi

Modello: S.L.U

Carico nominale: 10-250kn

Diametro: 10-32 mm

Peso: 0.2-3 kg

Garanzia: 1 anno

Evidenziare:

Heavy Duty Fixed Joints

10-250KN Rated Load Structural Joints

Permanent Structural Connections Mechanical Fasteners

Informazioni di base

Luogo di origine: Ningbo

Marca: Suntech

Certificazione: ISO

Numero di modello: S.L.U

Termini di pagamento e spedizione

Imballaggi particolari: Custodia in compensato

Tempi di consegna: 3-7 giorni

Termini di pagamento: L/C,T/T

Capacità di alimentazione: 30000 pezzi/mese

Galleria

Heavy Duty Fixed Joints with 10-250KN Rated Load for Permanent Structural Connections in Electrical Construction

Descrizione di prodotto

Heavy Duty Fixed Joints for Secure and Permanent Structural Connections

Heavy Duty Fixed Joints provide secure and permanent structural connections specifically designed for electrical construction applications. These mechanical fastening devices create strong, immovable connections between structural members in power infrastructure systems.

Product Specifications

Model	A (mm)	B (mm)	C (mm)	d (mm)	D (mm)	E (mm)	Rated Load (KN)	Weight (kg)
SLU-1	36	68	18	10	14	29	10	0.2
SLU-3	37	76	20	12	17	31	30	0.22
SLU-5	50	96	23	18	19	42	50	0.6
SLU-8	56	110	28	20	22	50	80	0.8
SLU-10	59	126	30	22	26	54	100	1.2
SLU-13	61	134	32	24	27	56	130	1.3
SLU-15	63	138	37	27	28	58	150	1.4
SLU-25	80	178	44	30	35	72	250	3.0
SLU-28	80	178	44	30	35	72	280	3.0
SLU-32	85	186	42	30	38	80	320	3.9

Key Features and Benefits

Permanent Rigid Structural Connections: Prevents all degrees of freedom between connected parts, creating monolithic structural units essential for maintaining precise geometry in electrical support systems.
Transmission Tower and Substation Frameworks: Essential for constructing steel lattice transmission towers and substation structural steel, forming triangulated frameworks that withstand massive forces.
Equipment Supports and Mounting Platforms: Used to fabricate robust support structures for transformers, circuit breakers, and other heavy electrical equipment in substations and power plants.
Cable Management Systems: Critical for assembling cable tray and conduit support systems, creating continuous rigid pathways that prevent sagging and misalignment.
Superior Load Transfer and Distribution: Efficiently transfers and distributes loads along intended paths, preventing localized failure and ensuring structural integrity.
Long-Term Dimensional Stability: Maintains precise shape and alignment over decades of service, resisting thermal expansion, wind vibration, and mechanical loads.
Pre-Engineered and Custom Configurations: Available in standardized forms and custom fabrications to meet specific project requirements and design optimizations.
Efficient Assembly Process: Designed for bolted connections enabling workshop pre-fabrication and quick on-site assembly, reducing field welding requirements.
Corrosion Protection: Typically hot-dip galvanized for durable protection against rust and corrosion in harsh environmental conditions.
Foundation for Electrical Infrastructure: Critical mechanical links that ensure the safety, reliability, and resilience of power generation, transmission, and distribution assets.

Fixed Joints are fundamental components in electrical construction, transforming individual steel members into cohesive, load-bearing structures. Their role in providing permanent rigidity, precise alignment, and efficient load transfer is essential for building the robust towers, substations, and support systems that form the physical backbone of the modern electrical grid.
